W530 D450 Wall-Mounted Server Rack Network Cabinet

**W530*D450 Wall Mount Cabinet With Removable Panel**

Standard:

Comply　with ANSI/EIA RS-310-D,IEC297-2,DIN41491,PART1,DIN41494,PART7,GB/3047.2-92

Feature:

1. Frame structure, easy to assemble and knock down.

2. Standard cabinet equipped with adjustable 19” mounting posts.

3. Removable side doors and tempered glass front door, safe and convenient with lock.

4. Cable entry on both of the top cover and bottom plate.

5. Fan hole available on the top cover.

6. Cabinet can be fastened directly and conveniently onto the wall just with screws.

7. Height from 6U-21U,width 530mm and 600,depth 450mm and 600mm,they are optional.

8. Flat package, easy to carry and saving space.

Loading Capacity:

Static loading is 60kg

Main material:

Part	Thickness of Steel	Surface finish
Frame	SPCC cold rolled steel 1.2mm	Degreasing, pickling, phosphoric, dip-coat primed, powder coat
Mounting post	SPCC cold rolled steel 1.5mm	Degreasing, pickling, phosphoric, dip-coat primed, powder coat
Others	SPCC cold rolled steel 1.0mm	Degreasing, pickling, phosphoric, dip-coat primed, powder coat

Main Specification (mm):
